R-SHT: a State History Tree with R-Tree Properties for Analysis and Visualization of Highly Parallel System Traces

Abstract

Understanding the behaviour of distributed computer systems with many threads and resources is a challenging task. Dynamic analysis tools such as tracers have been developed to assist programmers in debugging and optimizing the performance of such systems. However, complex systems can generate huge traces, with billions of events, which are hard to analyze manually. Trace visualization and analysis programs aim to solve this problem. Such software needs fast access to data, which a linear search through the trace cannot provide. Several programs have resorted to stateful analysis to rearrange data into more query friendly structures.

In previous work, we suggested modifications to the State History Tree (SHT) data structure to correct its disk and memory usage. While the improved structure, eSHT, made near optimal disk usage and had reduced memory usage, we found that query performance, while twice as fast, exhibited scaling limitations.

In this paper, we proposed a new structure using R-Tree techniques to improve query performance. We explain the hybrid scheme and algorithms used to optimize the structure to model the expected behaviour. Finally, we benchmark the data structure on highly parallel traces and on a demanding trace visualization use case.

Our results show that the hybrid R-SHT structure retains the eSHT’s optimal disk usage properties while providing several orders of magnitude speed up to queries on highly parallel traces.
